EXACT ION with lithium-ion technology
![ANGLE EXACT 12V-12-400]( "ANGLE EXACT 12V-12-400")
![ANGLE EXACT 12V-12-400]( "ANGLE EXACT 12V-12-400")
![ANGLE EXACT 12V-12-400]( "ANGLE EXACT 12V-12-400")
![ANGLE EXACT 12V-12-400]( "ANGLE EXACT 12V-12-400")
ANGLE EXACT 12V-12-400 Industrial
ANGLE EXACT 12V-12-400 Industrial
Smaller, shorter, lighter – The most ergonomic production screwdriver!
Functions & key features
ANGLE EXACT 12V-12-400 Professional
0 602 496 600
ANGLE EXACT 12V-12-400 Industrial
Your Selection
Order number: 0 602 496 600
Recommended retail price excluding VAT
Included in this variant
-
Cardboard box
Technical data
Additional data
Torque (hard)
3 – 10 Nm
Speed
74 – 370 rpm
Description
Can be used with the new 12V angle head and the existing 180W angle heads (additional adaptor needed).
Torque, from (hard)
3 Nm
Torque, to (hard)
10 Nm
Torque, from (soft)
3 Nm
Torque, to (soft)
10 Nm
Torque (soft)
3 – 10 Nm
Speed, from
74 rpm
Speed, up to
370 rpm
Direction of rotation
R/L
Weight
1 kg
Comment
No load speed with Power Boost up to 500 rpm, maximum torque 12 Nm
Below 50% speed setting eventually lower power
Machine capability testing is done at 400 rpm according to VDI 2647.
Changes to the tool speed and torque may also affect accuracy.
Please verify machine capability at your specific setting.
Battery
GBA 12V
Drive type
Battery
Design
Angle
Connector type
Shut-off clutch
* You can find more information about the deviations in the following link:
