Angle measurers and inclinometers

GIM 120 Professional

Digital Inclinometer

Longer for maximum precision

Measures precise tilts in degrees, percent or millimetres/metres
Direction arrows and audible signals at 0° and 90° for easy alignment
Measured values automatically turn on the display when working overhead

Functions & key features

Your Selection

with 4 x battery (AA), Protective Bag

Show variant

1,229.00 MYR

Recommended retail price excluding VAT

Check availability on location

Find a local dealer

Your Selected Variant

with 4 x battery (AA), Protective Bag 0 601 076 800

1,229.00 MYR

Recommended retail price excluding VAT

Find a local dealer

GIM 120 Professional

Your Selection

with 4 x battery (AA), Protective Bag

Order number: 0 601 076 800

1,229.00 MYR

Recommended retail price excluding VAT

Find a local dealer

Included in this variant

Protective Bag
4 x 1.5 V LR6 battery (AA)

Your selection

Technical data

Additional data
Length	120 cm
Measurement range	0 – 360° (4 x 90°)
Electronics measurement accuracy 0°/90°	± 0.05°
Electronics measuring accuracy at 1– 89°	± 0.2°
Measurement accuracy, vials	± 0.057° = ± 1 mm/m
Power supply, inclination measurement	1 x 9 V 6LR61
Operating duration, inclination measurem., approx.	200 h
Weight approx.	1.3 kg
Units of measurement	°, %, mm/m

* Plus use-dependent deviation. You can find more information about the deviations in the following link: Technical features of products

** You can find more information about the deviations in the following link: Technical features of products

Find the right spare part

Our products can be clearly identified using the ten-digit part number on the tool. Please make sure that the part number below matches the number in the information box on your tool. If the part number below does not match the one on your tool, please use our spare parts catalogue to search directly for the part you require.
